MCT226
Material
Zinc alloy, 50 steel, 40Cr, 4Cr13martensite stainless steel blade, spring steel, TPE & PP handle, ABS ;
Function
This Versatile Crimping Plier is suitable for network construction and can independently complete the termination of RJ45/RJ11 modular plugs. It can strip the cable sheath, cut the cable, and crimping the shielded plug's dovetail clip.
Implementation Standards
GB/T 6290-2013, GB/T 699-1999, GB/T 3077-2015
Product Package
1pcs/box
Quality Warranty
1 year warranty
Specifications
| Model no. | MCT226 |
| Product Type | Termination tool |
| Termination Style | RJ11/RJ45 shielded & unshielded |
| Handle Material | PP + TPE |
| Blade Material | 4Cr13 martensite stainless steel |
| RJ45/RJ11 Termination Pocket | Zinc alloy die-casting, nickel-plated in silver-white color |
| Spring Material | Spring Steel |
| Switch Structure | Automatical ON/OFF |
| Strip Structure | Adaptively Strip slot |
| Standard Compliance | GB/T 6290-2013, GB/T 699-1999, GB/T 3077-2015 |
| Handle open angle | 22~23° |
Packaging Detail
| Std. Pkg. Qty. | 1 |
| Std. Pkg. Size(L*W*H, mm) | 212*72*21 |
Hear from users
Adopted a lot of suggestions from the frontline
It took 1 year and 3 months for R&D.
This Versatile Crimping Plier is suitable for network construction and can independently complete the termination of RJ45/RJ11 modular plugs. It can strip the cable sheath, cut the cable, and crimping the shielded plug's dovetail clip.
Made to be perfect
Adaptive Stripping Trough
RJ45/RJ11 Plug
The wire stripping structure base is an automatic lifting structure, composed of a spring and a plastic wire groove. This structure can automatically adjust its height according to the diameter of the cable to meet the stripping requirements of different cables, while ensuring that the wire core is not damaged.
