GXDH-50YP
Overview
Patch Panel Cat3 for voice system, unshielded, 50 ports
Description
Patch cord, Cat3, 50 ports. Made of Phosphor bronze/Polycarbonate/Carbon structural steel
Implementation Standards
ANSI/TIA568C.2，ISO/IEC11801-1:2008，YD/T926.3-2009
Quality Warranty
15 years warranty
Specifications
| Model no. | GXDH-50YP |
| Product Type | Patch Cord |
| Performance Level | Category 3 |
| Shield Type | UTP |
| Implementation Standards | ANSI/TIA568C.2，ISO/IEC11801-1:2008，YD/T926.3-2009 |
| Min.Dielectric Withstand Voltage(contact to contact) | 1000V DC or AC peak |
| Ports | 50 |
| Operating Temperature(℃) | -10~60℃ |
| Number of Plug Insertion & Termination Cycles | Plug>1000, termination>250 |
| Min.Plug Retention Force | 50N |
| Quality Warranty | 15 years warranty |
Packaging Detail
| Std.Qty | 1 pcs |
